Modular Multi-Modal Imaging Engine

Multispectral Camera Lineup

Our imaging systems draw inspiration from the Cambrian Explosion, harnessing rapid innovation and diversification to create a platform capable of capturing a vast range of visual information with unprecedented detail and adaptability.

The Cambrian M-Series is the evolution of multi-modal imaging engines. It leverages decades of engineering, design and technical advancements in imaging.

The combination of modular sensor choices, with multiple modes through a single lens system, enables new measurement opportunities. Our experts will work with you to create the ideal system for your project.

Multispectral Camera

Cambrian M-Series Overview

Multiple Lens Options

  • Nikon and Canon
  • Telescope
  • Microscope
  • Endo/borescopes
  • Custom

Multiple Imaging Mode Options

  • Multi-spectral
  • Polarimetric
  • High Dynamic Range
  • Multi-Focal Length
  • Tilted depth of focus
  • Event Detector
  • Colorimetric
  • Spot Spectro-radiometer

Modular-Multi-Modal Imaging Engine

  • 3 Sensor
  • Simultaneous
  • Synchronized
  • Sub pixel registered capture of 3 video sensors

No Parallax

Sub pixel registration of all 3 sensors with optical matched field of view

Wide Spectral Coverage

Utilizing a proprietary optical design to deliver high optical transmission with low spherical and chromatic aberrations from 400-2200nm

Cambrian Core

Flexibility in Integration

Multispectral Camera

Multi-Modal

  • VIS/NIR/SWIR/Polarization/Spectroradiometer
  • Multi-Focal length (1,2,3 or 4x FL)
  • High Dynamic Range
    • 12 f-stop optical HDR
  • Tilted Sensors
  • Event Detector
  • Colorimetric

Multispectral

  • 3 Custom bands (VIS-SWIR)
  • NDVI (Green/RedEdge/NIR)
  • 5 Channel (RGB, NIR1, NIR2)
  • 7 Channel (RGB, RGB’, NIR)

Polarization

  • Polarization (0,45,90) or (0,60,120)
  • F-mount Lens
  • Canon Mount lens
  • Telescope
  • Microscope
  • Borescope
  • Custom (incorporate into your optical system)

3 channel optical engine

!

Multiple sensor options

!

F, T & B4 lens mount options

!

VIS-SWIR, polarization configurable

Precision subpixel alignment

Full resolution capture at up to 240fps

Additional Options

Cambrian Max

Plug and Play

Multispectral Camera

All the benefits of the Core PLUS

Rugged enclosure

Streamlined electrical interface

Separate trigger and output for each channel

Software developers kit (SDK) and viewer available

Additional Options

Cambrian Edge

Decisions at the Edge

Multispectral Camera

All of the benefits of Max PLUS

Powerful NVIDIA ORIN for edge computing

AI capability on the device

Ability to train and deploy customer AI models

Access to the Eoptic ML/AI training suite

Additional Options

The Cambrian M-Series is driving imaging innovation to the edge with an unparalled volume of synchronized data and analysis.
